Top Drive, TDS-11SA
JJC TEC
129991-01
| Status ketersediaan: | |
|---|---|
| Kuantitas: | |
| No | OEM Ref No | Deskripsi |
|---|---|---|
| 901 | 119547 | Seal, Wiper, 11.0dia-Rod |
| 902 | 30117775-2 | Ring, Retainer, Eksternal |
| 903 | 119358 | Bushing, lengan, split |
| 904 | 115176 | Bushing, lengan, 1.0x1.25 |
| 905 | 87605-1 | Kit, segel |
| 906 | 51300-381-B | O-ring |
| 907 | 30119319 | Ring, Glyd, 11.0dia-Rod |
| 908 | 30119357 | Cincin, dorong |
| 909 | 117826 | Cincin piston |
| 910 | 30119143 | Ring, Glyd, 11,5 Dia-Rod |
| 911 | 110147-4 | Shim, Reservoir, .031 TDS9S |
| 912 | 98290 | Liner, batang, atas |
| 913 | 30154362 | Perisai, bantalan, lubang kecil, TDS 4S |
| 914 | 51216-24 | Pin, dowel |
| 915 | 53200-242 | Perekat sealant thread locker locker fasteners prop |
| 916 | 120117 | Sabuk, waktu |
| 917 | 108235-3 | SEAL, AC-MOTOR, DRIVE-END, TDS9S |
| 918 | 108235-4 | Segel, AC-Motor, TDS9 Nondrive-End |
| 919 | 109528-1 | Pad gesekan, rem kaliper |
| 920 | 110147-1 | SHIM, RESERVOIR, .002 TDS9S |
| 921 | 110147-2 | Shim, reservoir, .005 |
| 922 | 110147-3 | Shim, reservoir, .010 tds9s |
| 923 | 30151951 | Lengan, pin tembakan, ph-100 |
| 924 | 30151954 | Bantalan, radial, cahaya |
| 925 | 30158011 | Motor hyd, torsi tinggi kecepatan rendah yang dimodifikasi |
| 926 | 51300-226-B | O-ring |
| 927 | 108235-15 | Bantalan, ujung drive, motor, AC, TDS9 |
| 928 | 108235-2 | BEARING, AC-MOTOR, NON-DRIVE END TDS9S |
| 929 | 51300-038-B | O-ring |
| 930 | 51300-214-B | O-ring |
| 931 | 51300-152-B | O-ring |
| 932 | 30156256 | GEAR, PINION, PIN TEMBAK, PH-100 |
| 933 | 30173958 | Pin, tembakan, pH-100 |
| 934 | 110056 | Segel, batang, 1.5bore |
| 935 | 98898 | Engkol, assy, eksternal |
| 936 | 30158164 | Pin, engkol |
| 937 | 110703 | Actuator Assy, Counter Balance |
| 938 | 110704 | Aktuator, Assy, Counter Balance |
| 939 | 110191-501 | Kandung kemih, reservoir 4 galon |
| 940 | 110132 | Gasket, tutup |
| 941 | 30119592 | Silinder Assy, Link Tilt, TDS9SA/TDS11SA |
| 942 | 30157287 | Penjepit, silinder, assy, ph75 |
| 943 | 30157225 | Kuk, aktuator ibop, ph75 |
| 944 | 79824 | Bantalan, pengikut cam |
| 945 | 51300-220-B | O-RING CRANK ASSY, TDS |
| 946 | 118844-16-08 | Bushing, lengan, 1.00x0.50, fiberglide |
| 947 | 118844-22-22 | Bushing, lengan, 1.38x1.38, fiberglide |
| 948 | 30172825 | RETENSI GANDA PIN PIVOT |
| 949 | 71847 | Bantalan, kamera, pengikut |
| 950 | 118844-16-24 | Bushing, lengan, 1.00x1.50, fiberglide |
| 951 | 30157292 | PASANG, MUSIM SEMI, SILINDER PENJEPIT |
| 952 | 30172154 | PIN, PEMASANGAN SILINDER, PH-50 |
| 953 | 30157318-1 | SPACER, PENJEPIT |
| 954 | 30157318-2 | SPACER, PENJEPIT |
| 955 | 30157318-3 | SPACER, PENJEPIT |
| 956 | 118844-16-12 | Bushing, lengan, 1.00x0.75, fiberglide |
| 957 | 118463-2 | Manifold, Assy, Link Tilt Cylinder (Alum) |
| 958 | 122367 | BAUT |
| 959 | 76666-2 | Sub Sub, N.Sea |
| 960 | 125594 | SILINDER, HYD, IBOP, AKTUATOR, ASSY, PH100 |
| 961 | 30157308 | MUSIM SEMI |
| 962 | 121979+30 | RETAINER, BUSHING, SILINDER, GUNUNG |
| 963 | 30123563 | ASSY, KEMASAN KOTAK, PIPA CUCI 3', TDS |
| 964 | 123284 | NUT, 3' PIPA CUCI |
| 965 | 123292-2 | Set Pengepakan (5pcs) |
| 966 | 51300-348-F | O-ring |
| 967 | 30123562 | CINCIN, SNAP, 3' PIPA CUCI, TDS |
| 968 | 119387 | Pin, pawang pipa |
| 969 | 114416-1 | Kit, filter, hidrolik-minyak (filter) |
| 970 | 109567-E | TDS9S Cover, Akhiri |
| 971 | 109567-S | SEGEL TDS9S, TUBUH |
| 972 | 109567-T | PELAT TDS9S, DORONG |
| 973 | 108119-16b | Pasang pemandangan |
| 974 | 71033 | PAKING |
| 975 | 112640 | ADAPTOR, POMPA/MOTOR |
| 976 | 110023 | Coupling, Pump, Hyd, .750Borex1.375Bore |
| 977 | 30156326-36S | Hidrolik motro berkecepatan rendah/torsi tinggi |
| 978 | 109567-H203 | TDS9S Hosing, Gear |
| 979 | 109567-B | BANTALAN TDS9S, ROL |
| 980 | 109567-G20 | PERALATAN TDS9S, SET |
| 981 | 114083 | TABUNG, ASSY, KASUS-DRAIN |
| 982 | 56541-16 | KIT, FLANGE TERPISAH |
| 983 | 56541-12 | KIT, FLANGE TERPISAH |
| 984 | 55909-12-12 | Nipple Valved 3/4 ', QD Aeroquip |
| 985 | 109542 | Pompa, hyd, pistion, pres.comp |
| 986 | 107783-5C11R | Pompa, hyd, vane 1.0cu, in/mnt |
| 987 | 110562-1 | Akumulator TDS9S, Hydro-Pneu 6 ' |
| 988 | 110563-1 | Akumulator, hidro-pneu 4 ' |
| 989 | 110564-1 | TDS9S ACCUM, HYDRO-PNE 2 ' |
| 990 | 111712 | Mfld asy, prefill vlve ** |
| 991 | 30111013 | Assy, filter, 60-mikron, oli |
| 992 | 30173216 | Filter, hidrolik |
| 993 | 53003-16 | Plug, sq hd magnetic |
| 994 | 51218-18 | Locknut, bantalan |
| 995 | 51217-18 | Lockwasher, bantalan |
| 996 | 107865-16 | Saringan HPU PDM |
| 997 | 71613 | Beareather, reservoir |
| 998 | 30113165 | Katup, relief, .750npt |
| 999 | 51300-277-B | O-ring |
| 1000 | 51300-279-B | O-ring |
